Ecowitt WS90 7-in-1 Weather Station Powered by Shelly

Back Soon

Regular price: £180.00 GBP
Sale price: £180.00 GBP
Regular price

UK VAT included. Shipping calculated at checkout.

Usage note:

To use this device with the Shelly Smart Control app, a gateway is necessary. Compatible gateways are Shelly BLU Gateway, or any Shelly Plus, Pro, Gen3 or Gen4 device (excluding sensors). Not compatible with Ecowitt gateways or consoles.

WS90 Powered by Shelly version vs WS90 Standard (RF) version – Selection Guide, FAQs & Recommendations

1. Does the Shelly version support local display on an Ecowitt console?

Unfortunately, the short answer is no.

The WS90 Powered by Shelly replaces the WS90 standard Sub-G RF (868MHz radio frequency) transmitter with a Bluetooth/Zigbee module.

Protocol Conflict: Conventional TFT displays (like the Ecowitt HP2550 or HP2560) "listen" exclusively on the 915MHz/868MHz/433MHz RF frequency.
Hardware Limitation: Because the Shelly version does not broadcast on those RF frequencies, a standard desk display will not be able to "see" or display the data from a Shelly-branded WS90.

The workaround solution: If you want both a local desk display and Shelly automation, we recommend purchasing the Standard WS90 with a display console. You can then bridge the data into your Shelly/Home Automation world using a "local push" or a platform like Home Assistant.

2. Power Consumption

There is a distinction between the "Power to Run" and the "Power to Heat."

Sensor Power (The AA Batteries)

The sensors (wind, rain, temp) consume a minuscule amount of energy.

Autonomy: Using high-quality Lithium AA batteries (not Alkaline), the station can operate for 1 to 2 years without any solar assistance at all.
Rainy Days: Even if it is cloudy for three weeks, the batteries will easily bridge the gap. The station will not go offline unless the batteries are physically exhausted, which takes a very long time.

Heater Power (The 12V Input)

The "power-hungry" part is the internal heater used to melt snow/ice.

Requirement: This only works if you have a 12V DC power supply plugged in.
Autonomy Tip: If you do not provide 12V power, the heater simply stays off. The station will still report temperature, rain, and wind perfectly fine—the only risk is that if the unit physically freezes over with ice, the wind readings will be "0" until it thaws naturally.

3. How to Maximize Autonomy

Since you are concerned about being away for long periods, we suggest two ways to ensure the station never dies:

Option A: The Battery Extension Kit. We offer a kit that moves the battery compartment from the top of the unit to a box 10 meters down the pole. This makes it easier to swap them without a ladder.
Option B: External 12V Battery & Solar. If you truly want the heater to work in a remote location, you can install a small, separate 20W solar panel connected to a 12V lead-acid or LiFePO4 battery. You then plug that 12V battery into the WS90's power input. This provides "infinite" autonomy for both the sensors and the heater.

Summary table to help your decision:

Feature	WS90 Standard (RF)	WS90 Powered by Shelly
Local TFT/LCD Display	Yes(Native support)	No
Shelly Cloud	Via Hub/API	Yes(Native support)
Range	Very Long (RF)	Moderate (BT/Zigbee)
Battery Life	1–2 Years (Lithium)	1–2 Years (Lithium)

Features

7-in-1 Wireless Haptic Sensor Array - Ultrasonic wind monitoring, haptic rain detection, temperature & humidity tracking, UV, and Illuminance measurements
Dual Connectivity - Bluetooth and Zigbee run simultaneously for effortless setup and reliable automations
High-Precision Sensors - Temperature range -40 to +60 °C and humidity 0-99% RH for dependable weather insights
Low-Maintenance Design - Solid-state sensors with no moving parts for long-lasting use
Always Connected - Reports to multiple gateways at once, using Shelly devices for Bluetooth and any compatible Zigbee hub for broader smart home integration
Pressure Trend Alerts - Know when the weather is likely to improve or worsen directly in the Shelly app
Your Weather, Visualized - Easy-to-read Shelly Smart Control app turns live data into clear insights
Tailored to Your Location - Adjust sensor offsets so readings reflect your unique surroundings
Solar-Powered with Backup - Solar operation with AA battery backup for continuous operation
Built for the Outdoors - IPX5-rated housing, stable even in harsh conditions

Specification

Sensors	Measurement	Range	Accuracy	Resolution
	Wind Speed	0 m/s to 40 m/s	<10 m/s ±1 m/s; ≥10 m/s ±10%	0.1 m/s
	Wind Direction	0° to 359°	±15°	1°
	Temperature	-40°C to 60°C	±1°C	0.1°C
	Humidity	1% RH to 99% RH	±5%	1% RH
	Light	0 klx to 200 klx	±25%	0.1 klx
	UV Index	1 to 15	±2	1
	Rainfall	0 mm to 9999 mm	<5 mm/h ±20%; 5–50 mm/h ±10%; >50 mm/h ±20%	0.1 mm
	Barometric Pressure	300 to 1100 hPa	±1 hPa	0.1 hPa
Physical	Size(HxWxD)	208 x 93 x93 mm/8.19 x3.66 x 3.66 inch
	Weight	459g/16.2 oz (without batteries), 507 g/ 17.88 oz (with batteries)
	Mounting	On a ∅25 mm/ 1 inch pole
	Shell material	Plastic
	Shell color	white
Electrical	Power supply	2 x AA 1.5V Lithium batteries(not included) Built-in solar panel 7.5V ±5%/30 mA ±10% 12V DC/1A external power supply(not included)
Electrical	Estimated battery life	Up to 6 months with lithium batteries (depending on temperature, humidity, and network strength).
Bluetooth	Protocol	Bluetooth 5 Low Energy
	RF band	2402-2480 MHz
	Max. RF power	< 20 dBm
	Range	Range: Up to 20 m/66 ft indoors and 30 m/ 100 ft outdoors (Depends on local conditions)
Zigbee	Protocols	802.15.4
	RF bands	2405 to 2480 MHz
	Max. RF Power	< 20 dBm
	Range	Up to 100 m/328 ft indoors and 300 meters 984 ft outdoors (Depends on local conditions)

Included

1 x Weather Station Ecowitt WS90(Powered by Shelly)
1 x User Manual
1 x 12V DC/1A Heater Power Supply with cable(optional)

Connectivity:
